12000.1D EVO



THE NEW EVO LINE is here to stay and has every resource to produce the perfect sound. Quality, efficiency, stability, onboard crossover and innovative design.



READ MORE

TECHNICAL SPECIFICATIONS

12000.1D 1Ω
Power @ 12.6V @ 1Ω: 1 x 12000 W RMS
Power @ 12.6V @ 2Ω: 1 x 6600 W RMS
Power @ 12.6V @ 4Ω: 1 x 3630 W RMS
Power @ 14.4V @ 1Ω: 1 x 15672 W RMS
Power @ 14.4V @ 2Ω: 1 x 8620 W RMS
Power @ 14.4V @ 4Ω: 1 x 4741 W RMS
Operating Voltage: 9V – 16V
Current Draw (Music): 627A
Current Draw (Max): 1253A
THD + N – (10% Rated Power): 0.09%
Damping Factor: >1000
SNR: 74dB
Frequency Response: 5 Hz – 20 kHz
Crossover HPF: 5 Hz – 80 Hz
Crossover LPF: 80 Hz – 20 kHz
Bass Boost: 0 – 12dB
Bass Boost Range 35Hz – 70Hz
Recommended Fuse: 3 x 225A (Music) / 3 x 500A (SPL)
Dimensions (L x W x H): 20 x 9.06 x 2.8 in
