THE NEW EVO LINE is here to stay and has every resource to produce the perfect sound. Quality, efficiency, stability, onboard crossover and innovative design.
Now featuring a linear power supply with an efficiency over 90%, it is able to produce solid and longer bass sounds with the lowest consumption ever. When in standby, it can consume up to 5 times less than other products in the market.
READ MORE
4000.1D 1Ω
Power @ 12.6V @ 1Ω: 1 x 4000 W RMS
Power @ 12.6V @ 2Ω: 1 x 2200 W RMS
Power @ 12.6V @ 4Ω: 1 x 1210 W RMS
Power @ 14.4V @ 1Ω: 1 x 5224 W RMS
Power @ 14.4V @ 2Ω: 1 x 2873 W RMS
Power @ 14.4V @ 4Ω: 1 x 1580 W RMS
4000.1D 2Ω
Potência @ 12,6V @ 2Ω: 1 x 4000 W RMS
Potência @ 12,6V @ 4Ω: 1 x 2200 W RMS
Potência @ 14,4V @ 2Ω: 1 x 5224 W RMS
Potência @ 14,4V @ 4Ω: 1 x 2873 W RMS
Tensão de Trabalho: 9V – 16V
Consumo em Programa Musical: 209A
Consumo Máximo: 418A
Fusível recomendado: 200A
THD + N – (potência nominal): 0,1%
THD + N – (50% da potência nominal): 0,08%
THD + N – (10% da potência nominal): 0,08%
Fator de Amortecimento: >1000
SNR: 73dB
Frequency Response: 5 Hz – 20 kHz
Crossover HPF: 5Hz – 80Hz
Crossover LPF: 80Hz á 20KHz
Bass Boost: 0 – 12dB
Bass Boost Range: 35 Hz – 55 Hz
Recommended Fuse: 200 A (Music) / 2 x 200 A (SPL)
