1600.1D EVO



THE NEW EVO LINE is here to stay and has every resource to produce the perfect sound. Quality, efficiency, stability, onboard crossover and innovative design.



READ MORE

TECHNICAL SPECIFICATIONS

1600.1D 1Ω
Power @ 12.6V @ 1Ω: 1 x 1600 W RMS
Power @ 12.6V @ 2Ω: 1 x 880 W RMS
Power @ 12.6V @ 4Ω: 1 x 484 W RMS
Power @ 14.4V @ 1Ω: 1 x 2090 W RMS
Power @ 14.4V @ 2Ω: 1 x 1149 W RMS
Power @ 14.4V @ 4Ω: 1 x 632 W RMS
1600.1D 2Ω
Power @ 12.6V @ 2Ω: 1 x 1600 W RMS
Power @ 12.6V @ 4Ω: 1 x 880 W RMS
Power @ 14.4V @ 2Ω: 1 x 2090 W RMS
Power @ 14.4V @ 4Ω: 1 x 1149 W RMS
1600.1D 4Ω
Power @ 12.6V @ 4Ω: 1 x 1600 W RMS
Power @ 14.4V @ 4Ω: 1 x 2090 W RMS
Operating Voltage: 9V – 16V
Current Draw (Music): 87A
Current Draw (Max): 174A
THD + N – (10% Rated Power): 0.009%
Damping Factor: >1000
SNR: 96dB
Frequency Response: 5 Hz – 50 kHz
Crossover HPF: 5 Hz – 60 Hz (12 dB/oct)
Crossover LPF: 50 Hz – 500 Hz (24 dB/oct)
Bass Boost: 0 – 12dB
Bass Boost Range: 35 Hz – 55 Hz
Recommend Fuse: 100A (Music) / 175A (SPL)
Dimensions (L x W x H): 8.78 x 7.09 x 2.2 in
